2-00 Series Knobs - Contemporary Aluminum

SKU: 18bd5257e52e Category:
Request Quote

Knobs - Contemporary Double Pointer Knob

One-piece construction.  Rugged, functional design

2-00 Series – Double Pointer Knob
One-piece construction. Rugged, functional design
Available with or without index line
Available with or without colored insert
Standard Finish: Black or natural anodized

Tolerances +/- 1/64"

Aluminum Knobs, black or natural anodized

With or without colored insert; with or without index line filled.

*Standard knobs can be customized to meet your requirements or we can manufacture to your print.*

A’ Shaft = .127(3.23) +/- .001, two set screws located 120o  Apart

B’

Item # Dimension A (in) Dimension B Dimension C Dimension D Dimension E Dimension F Dimension G Thread Size Shaft Size
2-10 1.000 .906 1.109 1.375 .594 .750 .562 6-32 Inch A'-B'
2-75 .750 .671 .844 1.060 .594 .625 .474 6-32 Inch A'-B'
2-62 .625 .562 .703 .890 .578 .625 .474 6-32 Inch A'-B'
2-50 .500 .458 .563 .750 .438 .500 .375 6-32 Inch A'-B'
2-37 .375 .328 .438 .578 .281 .500 .375 4-40 Inch A'
